Series · Outdoor Fixed LED

Sun Flare

太阳耀斑 · 户外固装屏

A flare of the sun — made to outshine daylight. 太阳表面最耀眼的爆发——户外屏就是要压过正午的阳光。

SEC 01Platforms

A platform, not a single pitch.

Cabinet structure, module and service access stay constant — pixel pitch is selected per project against viewing distance.

SF320户外固装 · 全间距平台

320×160mm 主流模组

8 档间距 P2.0–P10 · IP65

P2.0 / P2.5 / P3.076 / P4.0 / P5.0 / P6.67 / P8.0 / P10

SF250户外固装 · 中间距段

250×250mm 经典模组

P2.604–P3.91（P2.6–P4 档）

P2.604 / P2.976 / P3.91

SEC 02SKU Register

Full SKU = platform – environment – pitch – size. Scan rate and brightness variants appear only at this level.

Full SKU	Platform	Env	Pitch	Size	Refresh Hz	Module
SF250-O-P2604	SF250	O	P2.604	250x250mm模组	7680	250x250
SF250-O-P2976	SF250	O	P2.976	250x250mm模组	7680	250x250
SF250-O-P391	SF250	O	P3.91	250x250mm模组	7680	250x250
SF320-O-P10	SF320	O	P1.0	320x160mm模组	7680	320x160
SF320-O-P20	SF320	O	P2.0	320x160mm模组	7680	320x160
SF320-O-P25	SF320	O	P2.5	320x160mm模组	7680	320x160
SF320-O-P3076	SF320	O	P3.076	320x160mm模组	7680	320x160
SF320-O-P40	SF320	O	P4.0	320x160mm模组	7680	320x160
SF320-O-P50	SF320	O	P5.0	320x160mm模组	7680	320x160
SF320-O-P667	SF320	O	P6.67	320x160mm模组	7680	320x160
SF320-O-P80	SF320	O	P8.0	320x160mm模组	7680	320x160

SEC 03Why SF

IP65sealed for permanent outdoor operation

5000–10000 nitsreadable against direct sunlight

Common cathode optionlower power draw on large facades

Front / rear servicefits both wall-mount and pole structures

Sun Flare cabinets combine sealed protection with high-brightness modules so content stays readable in direct sun and driving rain.
